LSNYB5-5 Nylon Insulated Locking Spade Terminals 12-10 AWG

Product image 1

LSNYB5-5 Nylon Insulated Locking Spade Terminals 12-10 AWG

Non insulated spade terminals lock in place for tight and secure connection in cramped spaces. They allow the user to quickly and easily terminate a connection without the need to remove the fastener. Internal barrel serrations ensure good wire contact and maximize tensile strength.

Dimensions & Features:

Wire Size: 12-10 AWG
Seam: Brazed
Stud Size: #10
Terminal Material: Tin-Plated Copper
Max Electrical Temperature: 105°C
Max Electrical Current: 50AMP
T: 1.0mm (0.04")
L: 25.2mm (0.99")
F: 7.0mm (0.28")
E: 13.0mm (0.51")
W: 9.0mm (0.35")
D: 6.4mm (0.25")
D1: 3.4mm (0.13")
D2: 5.3mm (0.21")
UL Recognized: Yes
CE Certified: Yes
RoHS Compliant: Yes

Product Drawing:

Cross References

Cross Reference Parts:
McMaster-Carr: 8007K39
Thomas Betts: RC10-10FL

Documents

Click to view product spec sheet:

Videos

Check out our YouTube channel!

$3.54

Original: $11.80

-70%
LSNYB5-5 Nylon Insulated Locking Spade Terminals 12-10 AWG—

$11.80

$3.54

Product Information

Shipping & Returns

Description

Non insulated spade terminals lock in place for tight and secure connection in cramped spaces. They allow the user to quickly and easily terminate a connection without the need to remove the fastener. Internal barrel serrations ensure good wire contact and maximize tensile strength.

Dimensions & Features:

Wire Size: 12-10 AWG
Seam: Brazed
Stud Size: #10
Terminal Material: Tin-Plated Copper
Max Electrical Temperature: 105°C
Max Electrical Current: 50AMP
T: 1.0mm (0.04")
L: 25.2mm (0.99")
F: 7.0mm (0.28")
E: 13.0mm (0.51")
W: 9.0mm (0.35")
D: 6.4mm (0.25")
D1: 3.4mm (0.13")
D2: 5.3mm (0.21")
UL Recognized: Yes
CE Certified: Yes
RoHS Compliant: Yes

Product Drawing:

Cross References

Cross Reference Parts:
McMaster-Carr: 8007K39
Thomas Betts: RC10-10FL

Documents

Click to view product spec sheet:

Videos

Check out our YouTube channel!
